ULD trailer

3-axlepivotingfor airport

High point loading due to narrow cross member spacing Waterproofed softwood floor, protruding beyond frame profiles 5 pairs of recessed foldable lashing rings Installation of axles from well-known manufacturers such as SAF or BPW OPTIONAL: Foldable, pivoting extensions, incl. extension planks for transporting wide loads OPTIONAL: Offset drawbar with pivoting eye 40 + 50 mm OPTIONAL: Version with side walls OPTIONAL: 2-part loading ramps with motor-hydraulic ramp actuators OPTIONAL: Ramps with hydraulic lateral movement, operated on semitrailer OPTIONAL: Plug-in retaining rails OPTIONAL: SmartBoard for reading data on vehicle display (mileage, axle assembly load, brake diagnostics etc.) TYPE DESIGNATION 3-AXLE LOW LOADER TRAILER - TYPE TÜP WEIGHTS Gross weight (techn.): 30 t Gross weight (perm.): 24 t Tare weight: approx. 5,9 t DIMENSIONS Approx. 7,000 mm = flat load surface Approx. 1,000 mm = rear access slope Total width: 2,550 mm Loading height, laden: approx. 960 mm FRAME Welded steel construction without front frame offset or body offset and drive-on taper at rear 4 pairs of mounting pockets for 100 x 5 0 mm tubular posts in external frame Recess in access slope for excavator shovel linkage 6 pairs of lashing points under external frame 5 pairs of recessed foldable 5 t lashing rings in floor (10 t techn. tensile strength)
