Titanium alloy rod
Ti-6Al-4VaerospaceAMS

Titanium alloy rod - WESTERN SUPERCONDUCTING TECHNOLOGIES CO LTD - Ti-6Al-4V / aerospace / AMS

Titanium alloy rod - WESTERN SUPERCONDUCTING TECHNOLOGIES CO LTD - Ti-6Al-4V / aerospace / AMS - image - 2

Titanium alloy rod - WESTERN SUPERCONDUCTING TECHNOLOGIES CO LTD - Ti-6Al-4V / aerospace / AMS - image - 3

Titanium alloy rod - WESTERN SUPERCONDUCTING TECHNOLOGIES CO LTD - Ti-6Al-4V / aerospace / AMS - image - 4

Add to favorites

Compare this product

Characteristics

Form

rod

Type

Ti-6Al-4V

Other characteristics

aerospace, AMS

Mechanical resistance

Max.: 895 MPa

Min.: 485 MPa

Typical elongation

9 %, 10 %

Diameter

Max.: 60 mm
(2.362 in)

Min.: 16 mm
(0.63 in)

Description

Ti-811 alloy is a kind of near α titanium alloy with high content of Al element, which was successfullyresearched in USA in 1954. It has excellent mechanical properties at the room temperature and high temperature, which tensile strength at the room temperature is similar with that of Ti-6Al-4V and tensile strength and creep properties at 425℃ high temperature is better than other α and α＋β titanium alloy. Due to higher Young’s modulus and good vibration damping performance, Ti-811 alloy can stably work for a long time at 450℃ temperature and is one of ideal material of the first three section of the blade on high pressure compressor of aero-engine. At present, WST can supply Ti-811 bars in size of dia.16-60mm with length of 500-3200mm according to AMS 4972G-2011.
