Aircraft antenna PA1000

UHF

The miniature S-Band Power Amplifiers Series PA1000 are designed for operation within industrial, naval, military and aerospace environments. The highly reliable and rugged design meets perfectly today's demands for small size, light weight and high efficiency. The PA1000 series Power Amplifiers are optimised to work best with STT’s TS1000 transmitters. The power amplifiers are designed to meet IRIG 106-96. NOTE: There are several options available to meet application specific requirements. Please do not hesitate to send us your inquiry for your specific needs. Environmental Temperature Range (operational) - -20°C to + 70°C at base plate (extended range -40°C to + 85°C) Shock - 100 g, 11 ms, half sine, 3 axis Vibration - 20 g, 20 Hz...2000 Hz, sinusoidal, 3 axis Altitude - unlimited Connectors RF-Connector - SMA or TNC Power Connector - PT1H8-4P or D-Sub 9 RF Frequency Range - 2200 to 2500 MHz Bandwidth - 100 MHz Output Power - 20 Watts Input Power - +20 to +30 dBm Physical Data Dimensions - 90 x 70 x 22 mm (L x W x H) Weight - approx. 270 grams
