Turning chuck GF 80 series

for aeronautics

INCH SERRATION BAR PULLING CHUCK Spring actuated bar pulling chuck For stationary outside clamping Application/customer benefi ts Clamping and positioning of short bar material. Positioning of shaft type components in automatic production cycle. Profi tability Direct mounting to the turret of the lathe - actuation device is not necessary. Suitable to all tool mounting systems. Only one tool place of turret is required. Simple production of special jaws for special bar profiles. High flexibility at small quantities. Simple set-up. Simple, safe spring pre-loading of jaws. Hardened / quenched clamping arms ensure long service life. Function Move bar pulling chuck GF onto the workpiece with the turret in Z-axis. The bar pulling chuck is clamping self acting via spring pre-loading. Open collet chuck. Move turret to position workpiece. Close collet chuck. Remove bar pulling chuck GF in Z-axis.
