Titanium alloy rod
platesheettube

titanium alloy rod
titanium alloy rod
titanium alloy rod
Add to favorites
Compare this product


Characteristics

Form
rod, plate, sheet, tube
Type
grade 5, grade 23
Other characteristics
aerospace
Mechanical resistance

Max.: 1,000 MPa

Min.: 895 MPa

Elasticity

Max.: 910 MPa

Min.: 828 MPa

Typical elongation

10 %, 18 %

Description

Ti-6Al-4V (Grade 5), classed as an alpha-beta alloy, is the most widely used of the high strength titanium alloys. The alloy combines its good mechanical strength and low density (4.42 kg/dm³) with excellent corrosion resistance in many media. OVERVIEW Grade 5 titanium is fully heat treatable (solution heat treatment plus aging) in sections up to 25mm and can be employed up to around 400°C. Ti-6Al-4V ELI (Grade 23) has a reduced oxygen content (0.13% max.) compared with Grade 5. This confers improved ductility and fracture toughness with some reduction in mechanical strength. Uses include fracture critical airframe structures and for offshore tubulars. CORROSION RESISTANCE Grade 5 titanium offers excellent resistance to many marine and offshore oil & gas environments. Titanium and its alloys resist a wide range of acid conditions being highly resistant to oxidising acids, possessing useful resistance to reducing acids and offering good resistance to most organic acids at lower concentrations and temperatures. Titanium should not be used with red fuming nitric acid and is rapidly attacked by hydrofluoric acid. The addition of 0.05% palladium (grade 24), 0.1% ruthenium (grade 29) or 0.05% palladium and 0.5% nickel (grade 25) significantly increases corrosion resistance in reducing acid chloride and sour environments, raising the threshold temperature to well over 200°C. TYPICAL APPLICATIONS Commercial applications for this engineering material include: Aero-engine componentsAirframe ComponentsMarine EquipmentOffshore Oil & Gas EquipmentAutosport ComponentsMedical Equipment We stock Grade 5 in flats, round bar, plate and sheet
