Towing tractor HF6150 series

for aircraftwith towbarwith flashing light

The HF6150 series aircraft, using European latest technology, is designed to push and pull all known narrow body and to certain extend medium body aircrafts. The maximum draw bar pull for this series is up to 121KN and the minimum is 72KN. The aircraft includes B717, B727, B737, B757, B767-200, A318, A319, A320, A321, A300, A310 or any aircraft below 300,000kg. Its ergonomic design provides agility, visibility, durable and reliable tractor. One of the unit designs is that it has three antenna type safety switches, similar to other raised cab heavy tractor. Any one of these touches an obstacle, it will stop the vehicle completely. This will prevent any accident happened. We use Deutz engine, Dana transmission, Dana front and rear axle. The visiability inside the driving cab is 360 degree. It is a reliable, economic and suitable for narrow body operation. Overall dimension(mm) 5270L 2110W 1960H（with optional cab） Max. Towing Pull (KN) 120 96 72 Wheelbase（mm） 2200 Front track（mm） 1790 Rear track（mm） 1790 Towing pin height（mm） 360 410 480 Towing pin length（mm） 402 207 Ground Clearance(mm) 165 Turning radius(mm) 3220（outside） Weight（kg） 15300
