Hydraulic press HG

formingfor aeronautics

BÊCHÉ counterblow hammers are predominantly used for manufacturing large and ultra-large forgings. The high impact energy and tonnage of the hammer dies, moving in opposite directions, permits precision forming of large forgings. Counterblow hammers with hydraulic drives are particularly well suited to the medium tonnage range. This means there is no need for a complicated compressed air installation. The DG series employs the proven pneumatic drive concept. It allows very large forging energy levels to be achieved. The sturdy design of the uprights, together with a solid guide system, ensures high precision during forging. Your advantages extremely high impact energy and tonnage high reliability and availability high stability of the overall structure high precision with large forgings hydraulic tup coupling long stroke for accessibility Description Range of application - large and oversized forged parts Stroke per ram hammer - up to 1.225 mm Work energy - 160 – 1.400 kJ Drive - HG series with hydraulic drive; DG series with pneumatic drive Max. blow rate - 25 - 50 bpm Material feeding - manual; robots Optional equipment die change systems tup heating systems ejector systems spraying systems
