Self-propelled refueller

for airport

1 chamber 2 baffles (1st baffle with bypass bypass) Top filling via the manhole DN 500 Bottom filling on the right Delivery right (unmeasured) Delivery at the rear via full hose (measured) 1 measuring system 1 stainless steel pump Full hose approx. 14 m DN 50 or Wet hose approx. 19 m DN 38 Stainless steel rear cabinet Empty weight from 5.900 kg Total vehicle length approx. 10.500 mm Special designs: Possible as a pressure tank Insulation 100 mm (stainless steel or Gfk insulating jacket) Ladder access options can be selected, e.g. from the side Rear area surveillance Reversing camera system and much more
