64-channel pressure scanner MPS4164

gasfor wind tunnelfor flight testing

Analog version of the MPS4264 Direct legacy compatibility with ZOC33 modules (replacement or operating side-by-side) New patented valve design provides “isolate-purge” On-board sensor excitation Unmatched sensor stability “CPx” (65psi) or “NPx” (90psi) valve control Up to 40kHz data output 4″H20 up to 50psi pressure range Overview The MPS4000 series miniature pressure scanners have been designed from the ground up to be a ‘game changer’ in the world of multi-channel miniature pressure measurement. The MPS4164 scanner is built around a brand new ultra-stable pressure sensor. Scanivalve has worked directly with a leading pressure sensor manufacturer to develop a custom packaging solution that allows us to maximize the transducer’s stability and accuracy. One of the significant improvements over the legacy miniature pressure scanners is the new, maintenance free valve design. The valve can be ordered in different configurations; “Normal” (NPx) and “Standard” (CPx). The normal (NPx) version of the valve defaults to the measurement mode and eliminates the need for any control pressure source except when changing the module state into Calibration / Purge mode. This can greatly simplify the system architecture and eliminate the need for multiple valves and a constant source of ‘muscle’ pressure.
