Tube stainless steel 625
for the aerospace industry

Add to favorites

Compare this product

Characteristics

Form

tube

Other characteristics

for the aerospace industry

Mechanical resistance

860,000,000 Pa
(124,732.5 psi)

Elasticity

205,000,000,000 Pa
(29,732,736.2 psi)

Typical elongation

45 %

Thickness

Max.: 5.53 mm
(0.218 in)

Min.: 0.41 mm
(0.016 in)

Diameter

Max.: 101.6 mm
(4 in)

Min.: 4.78 mm
(0.19 in)

Description

WELDED STAINLESS TUBING Welded and Drawn Stainless Steel Aerospace Tubing produced by Plymouth Tube’s Trent Mill. Size Range: OD: 0.188” – 4.00” (4.78mm – 101.60mm) Wall: 0.016” – 0.218” (0.406mm – 5.53mm) Specifications: 304/L : AMS 5565 (AMS-T-8506 canceled, supersedes MIL-T-8506) AMS 5567 (supersedes MIL-T-8504) AMS 5564, AMS 5566, AMS 5569 (AMS-T-6845 noncurrent, MIL-T-6845D canceled) 321: AMS 5567 (supersedes MIL-T8508, MIL-T-8606 & AMS-T-8606 inactive) AMS 5576 (MIL-T-6737 canceled) 347: AMS 5556 (supersedes MIL-T-8808, MIL-T-8606 inactive) AMS 5575 (MIL-T-6737 canceled) 625: AMS 5581 718: PWA 1065, TP-718 21-6-9: AMS 5561, BMS 7-185 17-7PH: AMS 5568
