Wire-cut EDM DR series

precision

FAST, DURABLE AND PRODUCTIVE Characteristics: Working table. The data input on the operador console is quick and simple. Drilling: with electrodes of 0,2 up to 3 mm at high speed. It is possible to drill: hardened steel, self-hardening steel, stainless steel, carbides, copper, aluminum. CT “compact tools” fixing system. Single and multi-channel. New electrote guides: higher precision, long duration, increased productivity. Guide made of hard metal. Extended travel length of the Z axis - 300 mm - 300 mm Machine dimensions (Length x Width x Height) - Length - 1.000 mm - 1.200 mm Width - 750 mm - 900 mm Height - 2.000 mm - 2.100 mm Worktable dimensions - 550 x 360 mm - 700 x 400 mm Allowable weight on table - 350 Kg - 500 Kg Generator intensity - 30 A - 30 A Voltage levels - 9 - 9 Electrode diameter - 0,2 – 3 mm - 0,2 – 3 mm Water tank capacity - 25 l - 25 l
