4-axis machining center NE
3-axisverticalfor aeronautics

Add to favorites

Compare this product

Go to the MULTIAX INTERNATIONAL CNC SRL website for more information

Characteristics

Number of axes

3-axis, 4-axis

Spindle orientation

vertical

Applications

for aeronautics, cutting, heavy-duty

Other characteristics

CNC, with fixed table

Rotational speed

Max.: 24,000 rpm
(150,796 rad.min-1)

Min.: 18,000 rpm
(113,097 rad.min-1)

X travel

2,600 mm, 5,150 mm
(102.36 in, 202.76 in)

Y travel

1,525 mm, 2,150 mm
(60.04 in, 84.65 in)

Z travel

400 mm, 600 mm
(15.75 in, 23.62 in)

Description

The NE Series machining centers are designed and built in the United States, can be custom configured to offer broad industry applications. NE Series features a compact CNC machining center with heavy-duty moving bridge structure, extra rigid construction, and is tailored to enable even the most intricate of jobs to be rapidly, reliably, and flawlessly executed. Configuration options include integrated tool touch off, point-to-point drill units, twin independent spindles, ultra-sonic cutting, 8-24 tool carousel, up to 20hp spindle motor, up to 600 mm (26") Z Axis Travel, multiple table sizes, custom table fixtures, auto loading and unloading roller-hold down, vacuum pumps, etc.
