Angular displacement sensor eddyNCDT 3060
non-contactinductiveeddy current

Angular displacement sensor - eddyNCDT 3060 - micro-epsilon - non-contact / inductive / eddy current
Angular displacement sensor - eddyNCDT 3060 - micro-epsilon - non-contact / inductive / eddy current
Angular displacement sensor - eddyNCDT 3060 - micro-epsilon - non-contact / inductive / eddy current - image - 2
Angular displacement sensor - eddyNCDT 3060 - micro-epsilon - non-contact / inductive / eddy current - image - 3
Add to favorites
Compare this product


Characteristics

Type
angular
Contact / non-contact
non-contact
Technology
inductive, eddy current
Other characteristics
compact
Applications
for aircraft
Domain
for the aerospace industry
Measuring range

Max.: 8 mm
(0.31 in)

Min.: 0.4 mm
(0.02 in)

Description

Non-contact, inductive displacement sensors from Micro-Epsilon operate according to the eddy current measuring principle. Unlike conventional, inductive displacement sensors, they measure on ferromagnetic and non-ferromagnetic materials providing high accuracy, frequency response and temperature stability. Due to their immunity to oil, dirt, pressure and temperature, these inductive eddy current sensors are primarily used for integration in machines and facilities. Characteristics Ideal for integration into plant and machinery Easy integration with modern fieldbus connection and smart signal processing Combination of resolution, linearity and temperature stability sets new standards Wide range of applications with numerous sensor models Maximum ease of use and intuitive configuration via web interface Sensors with measuring ranges ≥1 mm - Sensors with measuring ranges <1 mm 3-point calibration - 5-point calibration - 3-point calibration - 5-point calibration - - Switching and temperature outputs - - - Switching and temperature outputs - - Storage of multiple characteristics - - - Storage of multiple characteristics The new, powerful & inductive eddyNCDT 3060/3070 measuring systems are ideal for fast and precise displacement measurements. Equipped with a compact controller, a sensor and an integrated cable, these systems are factory-calibrated either for ferromagnetic or non-ferromagnetic materials. With numerous sensor models, high speed and smart signal processing, they define a new performance class in inductive displacement measurement.
