Metal cutting machine KASTOwa C 7

discfor aeronautics

KASTOwa C 7 Automatic circular sawing machine for fast, accurate sawing of large quantities of cut pieces of steel with tensile strength up to 1400 N/mm², also high alloyed with carbide tipped saw blades. The unique arrangement of saw gearing and four-point bar clamping guaranties the shortest possible cutting stroke. Fast feeding o the bar and hydraulically cushioned length gauge, as well as fast cycling, ensure high production rates of accurate cut pieces and high reliability. Cutting range Form Cutting range with blade Ø number of teeth 250x80 T 15 x 15 - 30 x 30 mm / 15 - 30 mm / 15 - 30 Ø mm Cutting range with blade Ø number of teeth 250x060 T 15 x 15 - 50 x 50 mm / 25 - 50 mm / 25 - 50 Ø mm Cutting range with blade Ø number of teeth 285x60 T 30 x 10 - 70 x 60 mm / 40 - 70 mm / 30 - 60 Ø mm Mass and height Length 1000 mm Width 1600 mm Height 2050 mm Total weight 1500 kg Material support height above floor 1000 mm Performance characteristics Drive power saw blade 5.5 kW Drive power hydraulic pump 1.4/1.8 kW Drive power coolant pump 0.12 kW Cutting speed infinitely variable 35- 140 / 35 - 140 / 40- 160 m/min Saw blade feed rate, infinitely adjustable 25 - 1000 mm/min Rapid return 8000 mm/min Clamping force, infinitely adjustable 8000 - 2000 N Max. tolerance of straightness 2 mm/min Bar length 1600- 6000 mm Storage depth 750 mm Max. single bar weight 200 kg Total load max. 2000 kg Bar pusher carriage feed motion 7.5 - 80 m/min Rapid return speed 80 m/min
