Noise management software ProCS™

programmingfor on-board systemavionics

Product Configuration Software (ProCS™) is available to enable the installer to configure all the necessary level settings and options into Jupiter Avionics Corporation (JAC) avionics equipment. The software guides the installer through a logical series of steps so that every aspect of the configuration parameters is covered. Connection from the computer to the JAC device is made using adapter cables. Refer to section 1.2.1. Access to the JAC device is via a 3.5mm jack socket. This may be labelled i/o or ♫/io on products with a faceplate or user controls. Refer to the product manual to confirm the location on other JAC products. The socket may be located on the main panel (for panel mount devices), beside the main connector (remote mount) or on one side of the wireless JAC device. This means that modification of any operating parameters can be achieved without disconnecting or removing the device from the aircraft The software also makes it simple to keep records of configuration specifics for different customers or missions To configure a JAC product, it is necessary to load the Product Configuration Software (ProCS™) onto a Windowsbased computer as described in section 2.3 of this manual. The cables in Cabling Option 1 below are provided as part of the Dealer Kit (JAC Part No. DLR-KIT) that is available to approved installers. The cable in Cabling option 2 may be purchased from JAC. For full connection information, refer to section 2.4. To determine if one or both of these options may be used, refer to the ProCS Setup line(s) for the specific device under consideration. (Normally, option 1 must be used for programming a JA95 or JRAC series Audio controller.)
