Self-propelled lavatory truck JSTY5050GWS

for airport

JSTY5050GWS Diesel Lavatory service Truck is a new type of aircraft sewage collection and water injection airport special vehicle modified by Jiangling chassis. It is designed as a rear lifting work platform, a large capacity cleaning and sewage tank, a hydraulic motor driven vacuum pump suction system (optional) and a hydraulic motor driven stainless steel acid resistant water pump. The vacuum pump suction system can efficiently and conveniently provide suction service for the aircraft sewage tank. The stainless steel pump driven by the hydraulic motor provides cleaning function for the aircraft sewage tank and sewage tank of the sewage truck. The chassis cab of the product is flat head, single row seat, two-door type, and the occupant is 2. The driving type is 4×2, the volume of clean water tank is 1.0m³, the volume of sewage tank is 2.0m³, and the water supply flow is ≥150min. The water supply pressure is 0.345Mpa, the sewage suction flow is 600L/min, and the height of the lifting platform from the ground is 400mm~2800mm. The product can be widely used in A300, A310, A318, A319, A320, A340, B707, B727, B737, B747, B757, B767, B777, DC8, 1L-18, 1L-62, MD11, MD80 and other models. Main technical parameters serial - Project Name - Specific parameters - Part Name - Model 1 - Total length (mm) - 6550 - chassis - JX1061TG25 2 - Total width (mm) - 1900 - engine - JX493ZLQ5 3 - Total height (mm) - 2150 - gearbox - JC528T8 4 - Wheelbase (mm) - 3360 - Front bridge - JMCQC600-E 5 - Wheel base (front/rear) (mm) - 1385/1425 - Rear axle - 8A-ABS5 6 - Front suspension (mm) - 1090 - tyre - 7.00R16 7 - Rear suspension (mm) - 2100 - Force extractor - SDQ51/74LGS-G
