Leakage testing machine HTT-03

electricpressuretemperature

IDEAL FOR PERFORMING INTERNAL LEAKAGE TESTS ACCORDING TO ITCAN / TARAN TEST PROCEDURES FEATURES Certified and listed in Boeing AMM • Operation via touchscreen • Set zero function with 4 x totalizing memory storage • Printer for printing recorded data • Automatic bypass in case of excessive flow • Integrated calibration menu • Hydraulic and electric components completely isolated from each other • Heavy duty stainless steel frame with drip tray • Mobile trolley on rigid and caster wheels • Weatherproof cover for operator panel • Doors for easy maintenance Model Suitable for HTT-01 All Airbus 3000psi, Boeing 747, 757, 767 and 777 HTT-02 Boeing 737 HTT-03 Airbus A350, A380 and Boeing 787 TECHNICAL DATA GENERAL Main power supply cable 5 meter Hydraulic hose to A/C system 6 meter HYDRAULIC Automatic bypass suitable for 225 l/min MEASUREMENT High pressure gauge HTT-01 and HTT-02: 0 - 4000 psi HTT-03: 0 - 6000 psi Accuracy 1% of full scale Temperature -25 - 100 °C Accuracy 0,4% of full scale Flowmeter Accuracy 0,3% of measured value Readout in l/min, gpm or cc/min POWER Supply voltage 1Ph. 85-132 or 176-264 V (automatic range switchover) Supply frequency 47-63 Hz Current 1,2 A
