Pressure tester HRT-06

avionicsfor enginesfor tachometer

IDEAL FOR FUNCTIONAL TEST OF RAM AIR TURBINE AS PER AMM FEATURES • High performance hydraulic motor • Handgrip for easy handling of the tool • Flange protector to prevent scratches to the aircraft ram air turbine • Internal flushing and cooling of the hydraulic motor • The ram air turbine of the aircraft will not be damaged in case of shaft seal failure of the hydraulic motor • Unique integrated feature to prevent cavitation of the hydraulic motor in case of emergency stop • Tool connects directly to the quick disconnect couplings of the hydraulic test stand • Heavy duty case with retractable extension handle and wheels TECHNICAL DATA REQUIREMENTS FOR HYDRAULIC TEST STAND Fluid Phosphate-Ester based fluids e.g. Skydrol or Hyjet Pressure 3000 PSI (210 bar) Flow 35 USgpm (132 l/min) Quick disconnect couplings: Config 1 Hycom HQD-010-HA Config 2 Hycom HQD-022-HA MOTOR LENGTH WIDTH HEIGHT WEIGHT 480 mm 200 mm 280 mm approx. 19 kg INCLUDING CASE LENGTH WIDTH HEIGHT WEIGHT 690 mm 530 mm 480 mm approx. 33 kg
