Aircraft battery SV-BAT-320

lead12 V

SV-BAT-320 provides at least an hour of power to a single SkyView display and all connected SkyView Network Modules, including the ADAHRS and EMS. Install one per display for maximum power failure redundancy. A system backup battery will provide over an hour of backup power to a Display and Modules. Each Display requires its own Backup Battery for redundancy. Rechargeable Li-lon battery with internal protection circuit Additional Information System Battery Backup: A system backup battery will provide over an hour of backup power to a Display and Modules. Each Display requires its own Backup Battery for redundancy. Connection: The SkyView Main Harness, included with each display, includes a lead and connector to attach to the SV-BAT-320. Mounting: The SV-BAT-320 should be mounted in the avionics bay, near the SkyView display. Mechanical specifications can be found on the Planning your SkyView System page.
