Rotary switch 1150

immersionstandard

320" Body Dia., with Panel Seal and Small Body Subminiature Precision Rotary Switches The Cole A1150 Rotary Switch has the same body diameter of the standard 1150, but the body length is longer, 0.360 inches. Its smaller shaft and ferrule are allowed to put a panel seal. The A1150 Rotary Switch is rated at 25,000 operational cycles. It has been engineered to meet all applicable requirements of MIL-DTL-3786. The A1150 Rotary Switch is rated at 25,000 operational cycles. It has been engineered to meet all applicable requirements of MIL-DTL-3786. The A1150 Rotary Switch is perfect for miniature switch applications where contamination control is a must and harsh environments are expected. The A1150 Rotary Switch allows for Long Life, Precision Switching, with the smallest possible footprint, while withstanding harsh conditions. Continuous (Non-Switching) Current Capacity - 3 Amps Switching Current Capacity 28 VDC Resistive - 0.2 Amps Switching Current Capacity 115 VAC Resistive - 0.15 Amps Switching Current Capacity 28 VDC Inductive (2.8 H.) - 0.1 Amps Low Level Capable - YES Switching Life - 25,000 cycles Weight - 4 grams Contact Surfaces - Gold Plated Vibration Tested - YES High Impact Shock Tested - YES Moisture Resistant - YES Salt Spray Resistant - YES Explosion Proof - YES Immersion Tested - YES RFI/EMI Tested - YES Screwdriver Slot - Available Shaft Seal - Available Panel Seal - Available Degrees - Max. Positions - Poles Available 36° - 10 - 1 or 2
