Horizontal balancing machine CMT-100 series

manualfor aeronauticsautomatic

At CIMAT, we produce and supply balancing machines for clutch assemblies and their components. These machines can be used by repair shops and manufacturing companies. High accuracy and efficiency are guaranteed thanks to special automatic (or manual) collet adapters with the highest clamping repeatability. Compensation of unbalance caused by eccentricity of adapter clamping. We’ve made component marking obsolete—our machines use the latest rotating speed measuring systems. Balancing reports can be saved as a PDF, CSV or XLS and can be sent to a built-in printer or to an ERP system—summary reports can also be created on request. Safety guarding standard ISO 21940-23:2012 (old ISO 7475 and DIN 45690)compliant. Permanent calibration and rotor specific calibration as standard. Intuitive and easy to operate software. Latest measuring and control unit ROTORTEST based on microprocessor technology. Different correction methods are supported: milling, drilling, grinding, punching, welding, adding balancing weights. Weight capacity of a rotor - 1 – 100 [kg] - 1 – 100 [kg] Hard-bearing and rotor specific calibration - Included - Included Max. diameter of a rotor with standard safety guarding - 500 [mm] - 650 [mm] Max. height of a rotor - up to 150 [mm] - up to 150 [mm] Special on-site driller - Included - Included Drive motor - AC motor with inverter - AC motor with inverter Safety guarding and CE label - Included - Included Weight of the machine - around 1500 [kg] - around 1500 [kg]
