Vertical balancing machine CMT-30 series

manualfor aeronauticsautomatic

At CIMAT, we produce and supply special balancing machines for single and dual mass flywheels. High accuracy and efficiency are guaranteed thanks to special automatic (or manual) collet adapters with the highest clamping repeatability On-site drilling or welding stations for mass correction Compensation of unbalance caused by eccentricity of adapter clamping We’ve made component marking obsolete—our machines use the latest rotating speed measuring systems Software converts amount of unbalance into value of mass to remove or add Balancing reports can be saved as a PDF, CSV or XLS and can be sent to a built-in printer or to an ERP system—summary reports can also be created on request Safety guarding standard ISO 21940-23:2012 (old ISO 7475 and DIN 45690) compliant Weight capacity of a component - od 0,2 do 30 [kg] - od 0,2 do 30 [kg] Rotor specific calibration - Included - Included Max. rotor diameter - 400 [mm] - 400 [mm] Max. rotor height - Do 200 [mm] - Do 200 [mm] Special on-site driller for mass correction - Included - N/A Adapter lock - Automatic - Automatic or manual Compressed air pressure - 0,6 [MPa] - 0,6 [MPa] Safety guard, CE label - Included - Included
