Accelerometer without display 3801A

1-axisMEMSpiezoresistive

Single axis MEMS accelerometer 3801A - Measurement range: ±2g to ±2000g - Non-Linearity: ±1%FS - Output: 0.10-12.0 mV/g - Operating temperature: -55 to +125ºC - Frequency response: Up to 5000Hz Model 3801A Accelerometer The Model 3801A is a mV output piezoresistive MEMS accelerometer in a rugged welded hermetic package. The accelerometer incorporates mechanical stops for over-range protection up to greater than 10,000g. The model 3801A is offered in ranges from ±2 to ±2000g and is gas damped to provide a wide frequency response. The accelerometer is temperature compensated to provide a stable output over the operating environment. Features - 10,000g Shock Protection - Hermetically Sealed - Gas Damping - mV Output - DC Response - Stud Mounting Applications - Impact Testing - Structural Testing - Test and Instrumentation - Environmental Testing - Vehicle Testing
