10 - 50hp piston engine 3W-112i B4 CS

10 - 50kgfor light aircraft4-stroke

Cylinder capacity - 114.0 ccm Power - 13.0 HP / 9.56 KW Bore diameter - 36.00 mm Stroke - 28.00 mm Rpm range - 1.000 – 7.000 U/min-1 Weight incl. ignition - 3.870 g Crankshaft - 3 ball bearing Piston rod - 3 ball bearing Oil/gasoline ratio - 1:50 - 1:80 (min. 92 Oktan) Ignition - 6.0 – 8.4 V DC The four cylinders and five-bearing crankshaft guarantee a quiet run. Vibrations are minimized whereby the model and electronics are preserved in the long term. The noise level is reduced at the same time. The engine is suitable for a broad variety of models and distinguishes itself through its reliability, durability, and power. The 3W Competition series (CS version) distinguishes itself through greater performance, more rapid response behaviour, and high torque. The engine thereby achieves a high standard of per-formance. Transfer ports in the cylinder and crankcase are modified. The microprocessor-controlled ignition enables simple engine control. The programmed ignition curve is exactly matched to the engines and guarantees good running characteristics in all rotation-al-speed ranges. The standard ignition can be operated with a voltage of 6 V up to 8.4 V (2-cell LiPo).
