Shell-end milling cutters

Diameter: 12 mm - 20 mm

Depth of cut <=25 mm (1 inch), max 30% ae Slotting depth max 50% Dc Insert corner radii range 0.2-1.6 mm (.008 - .063 inch)

Diameter: 25 mm - 200 mm

Max depth of cut 3 mm (0.118 inch) Recommended depth of cut 2 mm (0.079 inch) Double-sided insert, 16 cutting edges

Diameter: 16 mm - 25 mm

Max depth of cut 8 mm (0.315 inch) Excellent ramping capability Mirror-polished inserts

Diameter: 20 mm - 63 mm

Max depth of cut 4 mm (0.157 inch) Recommended slotting depth of cut 2 mm (0.079 inch) Insert corner radii range 0.4-0.8 mm (0.016-0.031 inch)

Max depth of cut 4.5 mm (0.177 inch) Recommended depth of cut 3 mm (0.118 inch) 4 cutting edges, single-sided inserts

Diameter: 76.2, 152.4 mm
Length: 44.5, 60.3 mm

Shell Mills Features and benefits Precision Coolant Technology (PCT). Coolant delivery exactly to cutting area. Increased heat transfer. Improved chip control.

Diameter: 152.4, 76.2 mm
Length: 44.5, 60.3 mm

Shell Mills Features and benefits Precision Coolant Technology (PCT). Coolant delivery exactly to cutting area. Increased heat transfer. Improved chip control.

Diameter: 43 mm - 180 mm
Length: 63.5, 50.8, 63 mm

Face Mills Features and benefits Use PCT technology, coolant through the insert. Engineered to provide the maximum performance in titanium machining. Anti-rotation feature enables up to six indexables rotations. Pocketing, ramping, ...

Diameter: 50.8, 63.5, 76.2, 101.6 mm
Length: 50.8 mm

First choice for face milling high-temp alloys and hard or hardened materials up to 60 HRC. Excellent productivity through massive reduction of machining time.

First choice for face and shoulder milling high-temperature alloys. Higher material removal rate due to fine pitch cutters. Secure clamping system, improving process stability and reliability. Effective ...

Face milling cutter with a 15° approach angle Four-edged system inserts in three sizes Wave-form finish along the flank face facilitates the choice of geometry Benefits for you: Cost-efficient high-feed ...
