Piston actuators

We design state-of-the-art hydraulic actuators for the commercial and military industrial markets. A trusted manufacturer of quality aircraft fluid control components since our establishment in 1954, our company — Crissair, ...

Stroke : 5.635 in - 14.041 in

... application. Design Features In general, lock actuators operate by interposing a radially displaced locking member between the moving piston and the stationary housing. In all locking actuators, ...

... position. Eight actuators are installed on each aircraft (four for each wing). TECHNICAL DATA: Operating Temperature: -54°C +107°C Operating Fluid: Skydrol Operating Pressure: 3000 psi (207 bar) Unit Weight: ...

Stroke : 206 mm

... 135°C Operating Pressure: 3000 psi (207 bar) Unit Weight: 2.1 kg Piston Load (Retraction): 10400 N Piston Load (Extension): 9200 N Piston Speed (Retraction): 0.2 m/sec max Piston ...

Stroke : 104 mm

Krueger Flap Actuator The Krueger Flap Actuator is an unbalanced, double effect linear hydraulic actuator. Both end positions of the actuator are held by internal locks, ...

Stroke : 135 mm

This Hydraulic Actuator is an unbalanced, double effect linear hydraulic actuator used to lower and raise the Main Entry Door of the aircraft by means of hydraulic force. Spherical end mounted, provided ...

Stroke : 88 mm

... Bias Actuator is a pneumatic actuator installed on the rudder control system of a business jet plane. In the event of an engine failure, the rudder bias actuators provide additional ...

Stroke : 100 mm

Pneumatic actuator that moves the tail in the correct position automatically when one engine is off. A solenoid driven Shut-off valve, when powered, connects the extension and retraction chambers of the RBA, zeroing ...
