Megohmmeters

Resistance range: 0.01 Ohm - 400,000 Ohm

The Megohmmeter Model 1050 is a 1000V Digital/Analog Insulation Tester. It is designed to facilitate testing by incorporating automatic measurement features and user friendly functions. The True Megohmmeter® ...

Resistance range: 30 kOhm - 10,000,000,000 kOhm

The Digital/Analog Megohmmeter Model 5050 is the latest design in 5000V insulation testers. Features include automatic calculation and presentation of the Dielectric Absorption Ratio (DAR), Polarization Index (PI) and ...

Resistance range: 30 kOhm - 10,000,000,000 kOhm

The Digital/Analog Megohmmeter Model 5060 is the latest design in 5000V insulation testers. Features include automatic calculation and presentation of the Dielectric Absorption Ratio (DAR), Polarization Index (PI) and ...

Resistance range: 30 kOhm - 10,000,000,000 kOhm

The Megohmmeter Model 5070 is a fully automated 5000V graphical insulation tester. This True Megohmmeter® features selectable and programmable test voltage (40 to 5100V) and programmable temperature correction ...

The Megohmmeter Model 6503 is a compact, self-contained, hand-cranked True Megohmmeter®. This practical and dependable instrument is designed for a broad range of plant and field service applications, ...

Resistance range: 10 kOhm - 10,000,000,000 kOhm

The Megohmmeter Model 6505 is a True Megohmmeter® portable instrument housed in a rugged field case that operates on either battery or line power. It performs voltage, insulation, and capacitance measurements. ...

Resistance range: 40 gOhm

True Megohmmeter® 1 kV Insulation and Continuity Tester 250V, 500V and 1000V Insulation Test Voltages Timed Test Mode up to 40 minutes for Insulation Resistance Test Test Lock feature for hands free timed measurements ...

Resistance range: 1,000 kOhm

True Megohmmeter® 50V, 100V, 250V, 500V and 1000V Insulation Test Voltages DAR and PI ratios calculated Timed Test Mode up to 40 minutes for Insulation Resistance Test Test Lock feature for hands free timed measurements ...

Resistance range: 4 mOhm - 4,000 mOhm

The Model 6527 is a portable multi-range True Megohmmeter® capable of measuring insulation resistance from 1kΩ to 4000MΩ. It has three user selectable test voltages of 250V, 500V and 1000V. The Model 6527 is also a multimeter ...

Resistance range: 999 kOhm - 1,000,000 kOhm

True Megohmmeter® 500V Insulation and Multi-Function Tester (Resistance, Continuity and Voltage) 10V, 25V, 100V, 250V and 500V Insulation Test Voltages 50GΩ Max Insulation Resistance Timed Test Mode up to 40 minutes ...

Resistance range: 200,000,000 kOhm

The SEFELEC 1000-M is the new generation EATON insulation resistance meter based and controlled by ARM-Dual Core and DSP technologies providing the best stability and repeatability. The high accuracy and measurement speed are suitable ...

Resistance range: 2,000,000,000,000 kOhm

These instructions present the SEFELEC1500M device, designed for taking measurements of high-value electrical resistance, as well as its electrical and mechanical specifications. In addition, the information required for usage in accordance ...

Resistance range: 1 kOhm - 10,000,000 kOhm

The 1865 + Megohmmeter/IR tester, with digital display, is used for high accuracy measurements of insulation resistance on a wide variety of components, materials and electronic devices. Resistance values greater than ...

Resistance range: 50 kOhm - 20,000,000 kOhm

... useful in measuring solid state diodes. An additional range on the 1864 Megohmmeter permits measurements up to 200 TΩ (2 x 1014 Ω) Stability of calibration in the GenRad 1864 Megohmmeter is maintained ...

Resistance range: 50 kOhm - 200,000,000 kOhm

... GenRad 1863 Megohmmeter is maintained by use of a four-transistor unity gain amplifier. Stable power supplies and feedback voltmeter circuit minimize drift and time wasting adjustments. Safety has not been overlooked ...

Resistance range: 50 kOhm - 2,000,000,000 kOhm

... in measuring solid state diodes. An additional range on the 1864-1644 Megohmmeter permits measurements up to 200 TΩ (2 x 1014Ω) Stability of calibration in the 1864-1644 Megohmmeter is maintained by ...

Resistance range: 1,000,000 Ohm - 200,000,000,000 Ohm

The Model R1M-A is a portable Megohmmeter designed to measure high values of resistance associated with the measurement of insulation resistance. It has six resistance ranges from 1 MΩ full scale to 200 GΩ full scale. ...

Resistance range: 1,000,000 Ohm - 200,000,000 Ohm

Handheld Megohmmeter1 MΩ TO 200 MΩ500V, 3.5 DigitThe Model R1M-B Handheld Voltmeter/ Megohmmeter is designed to measure insulation resistance in “live” circuits, which may have voltage present. It can ...

Resistance range: 20, 200, 2, 20 Ohm

The 620A-4 Igniter Circuit Tester is our flagship ohmmeter. A failsafe and portable digital ohmmeter specifically designed for ultra-safe resistance testing on squibs, flares, bridge-wire, and other explosive devices, the 620A-4 was the ...

Resistance range: 2, 20, 200, 20,000 Ohm

The AMPTEC 620BA failsafe ohmmeter was specifically designed for ultra-safe testing on squibs, flares, bridge-wire, and other explosive devices. The 620BA meets mid-range resistance requirements and offers a fail-safe current limiting ...

Resistance range: 2, 200, 200, 20,000 Ohm

The AMPTEC 620BH failsafe ohmmeter was specifically designed for ultra-safe testing on squibs, flares, bridge-wire, and other explosive devices. The 620BH meets mid-range resistance requirements and offers a fail-safe current limiting ...

Resistance range: 2,000, 2, 20, 200 kOhm

The AMPTEC 620EH failsafe ohmmeter was specifically designed for ultra-safe testing on squibs, flares, bridge-wire, and other explosive devices. The 620EH meets mid-range resistance requirements and offers a fail-safe current limiting ...

Resistance range: 2, 20, 200, 200 Ohm

The AMPTEC 620ES failsafe ohmmeter was specifically designed for ultra-safe testing on squibs, flares, bridge-wire, and other explosive devices. The 620ES meets mid-range resistance requirements and offers a fail-safe current limiting ...

Resistance range: 0 kOhm - 20,000 kOhm

The AMPTEC 620LM failsafe ohmmeter was specifically designed for ultra-safe testing on squibs, flares, bridge-wire, and other explosive devices. The 620LM meets a wide-range of resistance requirements, and comes standard with an (OP-232) ...

Resistance range: 200, 200, 20, 2, 20,000 kOhm

The AMPTEC 620MC failsafe ohmmeter was specifically designed for ultra-safe testing on squibs, flares, bridge-wire, and other explosive devices. The 620MC meets wide-range resistance requirements and offers a fail-safe current limiting ...

Resistance range: 0 kOhm - 2,000 kOhm

The AMPTEC 620MG failsafe ohmmeter was specifically designed for ultra-safe testing on squibs, flares, bridge-wire, and other explosive devices. The 620MG meets a wide-range of resistance requirements, and comes standard with an (OP-232) ...

Resistance range: 20, 200, 200 Ohm

The AMPTEC 620RK failsafe ohmmeter was specifically designed for ultra-safe testing on squibs, flares, bridge-wire, and other explosive devices. The 620RK meets mid-range resistance requirements, and comes standard with an (OP-232) RS232C ...

Resistance range: 0 kOhm - 2,000 kOhm

The AMPTEC 620UK Ohmmeter is a portable EEX digital igniter tester designed for ultra-safe resistance testing on squibs, flares, bridge-wire, and other explosive devices. The 620UK’s failsafe design allows it to comply with the EU ATEX ...
