Compact solenoid valves

DN: 0.875 in
Voltage: 28 V
Pressure: 5,000 psi

Lee miniature piloting solenoid valves are the most compact powered components we offer, available in a configuration just 0.875 of an inch in diameter and weighing less than 0.14 lbs. ...

Voltage: 28 V
Pressure: 3,000 psi

... our standard solenoid valves in terms of weight and compactness, but their unique Lee MultiSeal® design provides omnidirectional porting, allowing greater flexibility and potential weight savings when ...

DN: 0.75 in
Voltage: 18 V - 30 V
Pressure: 600, 2,200 psi

V3400 solenoid valves are specifically designed to meet the critical weight and size limitations in aircraft fuel control systems. They are well-suited for the extreme vibration, temperature, and cycle ...

DN: 0.188 in - 0.198 in
Voltage: 18 V - 30 V
Pressure: 1,200, 1,500, 3,000 psi

V4700 solenoid valves are designed for use with aviation fuels, non-corrosive gases, and non-aromatic hydraulic fluids. They are well-suited for the extreme vibration, temperature, and cycle life requirements ...

DN: 0.218 in
Voltage: 18 V - 30 V
Pressure: 1,200, 1,500, 3,000 psi

V5000 solenoid valves are designed for use with aviation fuels, non-corrosive gases, and non-aromatic hydraulic fluids. They are well-suited for the extreme vibration, temperature, and cycle life requirements found ...

DN: 1.53 in
Voltage: 18 V - 30 V
Pressure: 1,000, 1,500, 3,000 psi

V14500 solenoid valves are designed for use with aviation fuels, non-corrosive gases, and nonaromatic hydraulic fluids. They are well-suited for the extreme vibration, temperature, and cycle life requirements ...

DN: 1.875 in
Voltage: 18 V - 30 V
Pressure: 400, 600, 1,000 psi

V20000 solenoid valves are designed to control high flows of fuel vapor and non-corrosive liquids and gases. The use of venturi-style coaxial flow path enhances the flow capacity of the valve ...

Voltage: 18 V - 30 V
Pressure: 4,000, 6,000, 7,500 psi
Temperature range: -65 °F - 350 °F

V27200 solenoid valves are designed to control high flows of non-corrosive liquids and gases. (A modified version is available for corrosive gas and liquid service.) They are well-suited for extreme ...

DN: 1.5 in
Voltage: 18 V - 30 V
Pressure: 3,000, 4,500, 7,500 psi

... disassembled for cleaning in applications where the process media must be removed from the valve after use. The welded solenoid construction and metal-tometal seating make this valve ...

Voltage: 18 V - 30 V
Pressure: 0 psi - 360 psi
Temperature range: 0 °F - 150 °F

... and rocket operating conditions. The compact size and low weight allow these valves to be used in the tightest space available. The solenoid is a hermetically sealed dual coil latching ...

DN: 1.5 in - 2.5 in
Voltage: 18 V - 30 V
Pressure: 1,000, 1,500, 2,500 psi

V44700 valves are designed to handle hot gases and corrosive liquids, as well as cryogenic gases and liquids. Their compact size and low weight allow these valves to be used in the tightest ...

DN: 1.5 in
Voltage: 18 V - 30 V
Pressure: 2,250, 3,000 psi

V64000 valves are direct acting, coaxial, poppet solenoid shut-off valves that are well-suited for the extreme vibration, temperature, and cycle life requirements found in the most severe ...
